| Place of Origin: | China |
| Brand Name: | FASTPCBA |
| Certification: | IATF16949, ISO13485, ISO9001 |
| Model Number: | One-Stop PCBA Manufacturers |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 1 |
| Packaging Details: | PCB: Vacuum Packing/ PCBA: ESD Packing |
| Delivery Time: | 5 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 150000 Pieces per Month |
| Number Of Layers: | 1-48 | Material: | FR4, High TG FR4, High Frequency, Alum, FPC |
|---|---|---|---|
| Min Space: | 0.075mm | Sub-assembly: | Plastic,metal,screen |
| Max Size Of Finish Board: | 700*460mm | Package: | QFN,BGA,SSOP,PLCC,LGA |
| High Light: | Electronic PCB Assembly Service,Prototype PCBA Manufacturers,FR4 Prototype PCBA Manufacturers |
||
ADVANCED INSPECTION MACHINE:
FASTPCBA Co., LIMITED advanced PCB production and testing equipment purchased from the United States, Japan, Germany, Israel and other places to improve production testing and technical capabilities. Adopting international advanced process technology and advanced management methods, the technological level is constantly improved from their high standards and strict requirements.
PCB Capability
| Article | Description | Capability |
| Material | Laminate materials | FR4, High TG FR4, High Frequency, Alum, FPC... |
| Board Cutting | Number of layers | 1-48 |
| Min.thickness for inner layers (Cu thickness are excluded) |
0.003”(0.07mm) | |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” | |
| 4layer:0.01±0.008” | ||
| 8layer:0.01±0.008” | ||
| Bow and twist | no more than 7/1000 | |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z | |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) | |
| PTH hole tolerance | ±0.002″(0.005mm) | |
| NPTH hole tolerance | ±0.002″(0.005mm) | |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) | |
| Thickness | (0.012*0.017mm) | |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) | |
| Max Size of Finish Board | 700*460mm | |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | |
| PCB Outline | Square,circle,irregular(with jigs) | |
| Package | QFN,BGA,SSOP,PLCC,LGA | |
PRODUCT CONFIGURATION:
4/2 (optional 6-inch) image intensifier and megapixel digital camera;
90KV / 100KV-5 micron X-ray source
Simple mouse click operation to write detection program;
High detection repeat accuracy;
Rotational tilt of plus or minus 60 degrees allows unique perspectives to detect samples;
High-performance stage control;
Large navigation window-easy to locate and identify defective products;
Automatic BGA detection program accurately detects every BGA bubble
Make judgments according to customer needs and output Excel reports.
PRODUCT APPLICATION:
PCBA solder joint inspection (BGA, CSP, POP and other components inspection)
Battery (Pole piece solder joint defect detection, cell winding condition detection)
Electronic connectors (harnesses, cables, plugs, etc.)
Automotive electronics (testing of patch cords, dashboards, etc.)
Solar, photovoltaic (wafer solder joint inspection)
Testing for special industries such as aviation components
Semiconductor (package component inspection)
LED detection
Electronic module detection
Ceramic products testing
