| Place of Origin: | China |
| Brand Name: | FASTPCBA |
| Certification: | IATF16949, ISO13485, ISO9001 |
| Model Number: | PCB Assembly Service |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 1 |
| Packaging Details: | PCB: Vacuum Packing/ PCBA: ESD Packing |
| Delivery Time: | 5 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 150000 Pieces per Month |
| Number Of Layers: | 1-48 | Material: | FR4, High TG FR4, High Frequency, Alum, FPC |
|---|---|---|---|
| Min Space: | 0.075mm | Sub-assembly: | Plastic,metal,screen |
| PCB Outline: | Square,circle,irregular(with Jigs) | Max Size Of Finish Board: | 700*460mm |
| High Light: | One Stop Printed Circuit Board Assembly,EMS Printed Circuit Board Manufacturing,EMS Printed Circuit Board Assembly |
||
Process capability:
| Article | Description | Capability | |
| Sercive | PCB and SMT assembly with one-stop service | ||
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board cutting | Number of layers | 1-48 | |
|
Min.thickness for inner layers (Cu thickness are excluded) |
0.003”(0.07mm) | ||
| Board thickness | Standard | (0.1-4mm±10%) | |
| Min. | Single/Double:0.008±0.004” | ||
| 4layer:0.01±0.008” | |||
| 8layer:0.01±0.008” | |||
| Bow and twist | no more than 7/1000 | ||
| Copper weight | Outer Cu weight | 0.5-4 0z | |
| Inner Cu weight | 0.5-3 0z | ||
| Drilling | Min size | 0.0078”(0.2mm) | |
| Drill deviation | ±0.002″(0.05mm) | ||
| PTH hole tolerance | ±0.002″(0.005mm) | ||
| NPTH hole tolerance | ±0.002″(0.005mm) | ||
|
Solder mask
|
Color | Green,white,black,red,blue… | |
| Min solder mask clearanace | 0.003″(0.07mm) | ||
| Thickness | (0.012*0.017mm) | ||
| Silkscreen | Color | white,black,yellow,blue… | |
| Min size | 0.006″(0.15mm) | ||
| E-test | Function Test | 100% Functional test | |
| PCBA Testing | X-ray,AOI Test,Functional test | ||
| Pcb assembly | one-stop service electronic manufacxturer service | ||
| Component sourcing | Yes | ||
| Certificate | IATF16949, ISO13485, ISO9001 | ||
| Delivery time: | PCB | 3-8days | |
| PCBA | 10-20days | ||
| Tolerance of pcb | ±5% | ||
| Max size of finish board | 700*460mm | ||
| MOQ | NO MOQ (1pcs) | ||
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | ||
| PCB outline | Square,circle,irregular(with jigs) | ||
| package | QFN,BGA,SSOP,PLCC,LGA | ||
| Sub-assembly | Plastic,metal,screen | ||
As the most professional pcba assembly factory in shenzhen china, FASTPCBA have accumulated experience in automotive pcba, medical pcba, industrial pcba, smart home pcba, communication pcba, military pcba, aviation pcba etc.
FASTPCBA is the experienced pcba manufacturer with procurement team average pcba industry experience over 15 years, providing the most competitive pcba cost and high quality pcb components for customers of industrial control pcba, automotive pcba,medical pcba etc.
Due to quality oriented, FASTPCBA has continuous orders in such fierce competition pcba market environment, welcome to consult or send a inquiry to get competitive pcb quotation.
With and IATF16949 and ISO14000, 13485, 9001 certificates,ERP pcb process control online, experienced engineer team,complete ESD protection & dust free smt workshop, 9 steps pcb testing, ERP pcb process control online, complete ESD protection & dust free smt workshop, ensuring high quality pcb & pcba service.
As the most professional pcba assembly factory in shenzhen china, FASTPCBA have accumulated experience in automotive pcba, medical pcba, industrial pcba, smart home pcba, communication pcba, military pcba, aviation pcba etc.
