| Number Of Layers: | 1-48 | Min Space: | 0.075mm |
|---|---|---|---|
| Max Size Of Finish Board: | 700*460mm | Component Sourcing: | Yes |
| Min Line/space: | 0.075mm | PCBA Testing: | X-ray,AOI Test,Functional Test |
| High Light: | Smoke Detector Circuit Board Printing,Smoke Detector PCB Assembly Service,UL 94v0 PCB Assembly Service |
||
Technical Specification:
| Name | OEM China Medical Equipment PCB and PCBA Manufacturer |
| Layers | 1-48 |
| Board Shape | Retangular,round,slots,cutouts,complex,irregular |
| Board Type | Rigid, Flexible, Rigid-flexible |
| Board Material | FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc. |
| Board Cutting | Shear,V-score,Tab-routed |
| Finished Board Thickness | 0.2-7mm |
| Copper thickness | 0.5-6Oz |
| Solder Mask | Gree/yellow/black/Red |
| Max Board Dimensions | 20 inch*20inch or 500mm*500mm |
| Min Trace/Gap | 0.10mm, or 4mils |
| Min Drill Hole Diameter | 0.01'',0.25mm, or 10mils |
| Surface Finish | HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc. |
| Impedance Tolerance | ±5% |
| Copper Weight Tolerance | ± 0.25 oz |
| Design File Formate | Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG |
PCB Design & Layout
» Excellent Expertise in design tools: Allegro, Pads, and Mentor Expedition.
» High density SMT designs (BGA, uBGA, PCI, PCIE, CPCI…)
» Flex PCB designs of all sorts
» Complete assembly drawings
» In-Circuit Test data generation (ICT)
» Drill, panel and cutout drawings designed
» Professional fabrication documents created
» High-speed, multi-layer digital PCB designs- Bus routing, differential pairs, matched lengths; Fast PCB design in 2-3 days.
» Concentrate on the PCB design Wi-Fi Module, BLE Module, GPS Tracking application.RF Modules,Medical-Care devices,LED PCB Boards.
» Full control for the PCB design, from requirement, Schematic, PCB Layout, SI/PI/EMI inspection, we will locate the design issues in the inspection processing.
PCB Fabrication Center
We have produced all kinds of PCBs including FR4, FR1, CEM1, FPC, Metal Core PCB and Rogers PCB, etc. With the advantage of material and component sourcing channels, we have the ability of fast PCB sample--48 hours after order confirmation.
