Components Sourcing ENIG HASL Lead Free Surface SMT PCBA

Product Details:

Place of Origin:	China
Brand Name:	FASTPCBA
Certification:	ISO13485, IATF16949, ISO9001
Model Number:	SMT PCBA Assembly Services

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	USD 0.1-3/ pcs
Packaging Details:	1.Inner: PCB: Vacuum Packing PCBA: ESD Packing 2.Outer: Standard export carton 3.Customized package.
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Service:	One-stop Service	Layer Count:	1-48
Testing Service:	Function Test, 100% Test	Min Line/space:	0.075/0.075mm
Silkscreen:	Min Size 0.006″(0.15mm)	Min Solder Mask Clearanace:	0.003”(0.07mm)
High Light:	HASL SMT PCBA , Components Sourcing SMT PCBA

PCB Prototype Printed Circuit Board Assembly Services PCB Circuit Board For SMT


* PCB Processing Capacity:

Base Material	Normal Tg FR4, High Tg FR4, PTFE, Rogers, Low Dk/Df etc.
Solder Mask Color	Green, Red, Blue, White, Yellow, Purple, Black
Legend Color	white, yellow, black, red
Surface treatment type	ENIG, HASL, HAF, HAF LF, OSP, flash gold, gold finger, sterling silver
Max. layer-up(L)	50
Max. unit size (mm)	700*460mm
Max. & Min. board thickness (mm)	0.3/12
Board thickness tolerance (mm)	T<1.0mm: +/-0.1mm; T≥1.0mm: +/-10%
Min. mechanical drilling hole (mm)	0.15
Min. laser drilling hole diameter(mm)	0.075
Min. innerlay clearance(mm)	0.15
Min. hole edge to hole edge space(mm)	0.28
Max. finished copper thickness(um)	Outer Layer: 420 (12oz) Inner Layer: 210 (6oz)
Min. & Min. trace width (mm)	0.075 (3mil)
Solder mask thickness (um)	line corner : >8 (0.3mil) upon copper: >10 (0.4mil)
BGA pad (mm)	≥0.25 (HAL or HAL Free:0.35)
V-CUT blade position tolerance (mm)	+/-0.10
Impedence tolerance (%)	+/-5%
Min. legend width (mm)	0.1
Fire flame calss	94v0


* PCBA Processing Capacity:

Processing Service	One Stop PCB Assembly service, include components & plastic mold sourcing, SMT&DIP assembly and enclosure installation service.
SMT Assembly	5 SMT Lines(10 million chips per day (0402, 0201 with 8 million per day)
DIP Assembly	3 Production Lines(1.2 million pcs per day)
Cable & Wire Assembly	Standard & Customized
Enclosure Assembly	3 Production Lines(Each line has 15 assemblers and 2 quality control engineers)
Components Package	Smallest with 01005, various chips package as QFN,BGA,SSOP,PLCC,LGA
Testing	E-test, Probe flying, Function testing, Temperature cycling, X-ray, AOI
Equipment	DSP1008, XPM2820,YG200,YV88-XG, YV100XGP, UNI-AX8200,WS-4501,XPM2820
Conformal Coating	Yes
PCBA Packing	Bubble, Anti-Static package (or in your requirement)
MOQ	No MOQ(1PCS)
Factory Certificate	IATF16949, ISO13485, ISO9001

Components Sourcing ENIG HASL Lead Free Surface SMT PCBA 0

Components Sourcing ENIG HASL Lead Free Surface SMT PCBA 1

FASTPCBA is an expert at PCB and PCBA manufacture, could provide R&D support, prototype service, technical consultation, material sourcing, PCB assembly, conformal coating,washing, in-circuit test, function test, burn-in test, environment test, logistics and after-sales service.

We have got the ISO9001, ISO13485, ISO14000 and IATF16949 certifications, and we will carry on the management concept of "Quality superior, Service supreme, Reputation first" to provide the best service in production and sales to our global customers.
