Multilayer Prototype PCB Assembly
Product Details:
Place of Origin: China
Brand Name: FASTPCBA
Certification: IATF16949, ISO13485, ISO9001
Model Number: Flexible PCBs Assembly
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: 1
Packaging Details: PCB: Vacuum Packing/ PCBA: ESD Packing
Delivery Time: 5
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 150000 Pieces per Month
Contact Now
Detailed Product Description
Number Of Layers: 1-48 Min Space: 0.075mm
Sub-assembly: Plastic,metal,screen Max Size Of Finish Board: 700*460mm
Component Sourcing: Yes Material: FR4, High TG FR4, High Frequency, Alum, FPC
High Light:

Multilayer Prototype PCB Assembly


SMT Prototype PCB Assembly

SMT / DIP Multilayer Prototype PCB Assembly


Process capability:


Article Description Capability
Sercive PCB and SMT assembly with one-stop service
Material Laminate materials FR4, high TG FR4, high frequency, alum, FPC
Board cutting Number of layers 1-48

Min.thickness for inner layers

(Cu thickness are excluded)

Board thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
Bow and twist no more than 7/1000
Copper weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)

Solder mask


Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
E-test Function Test 100% Functional test
PCBA Testing X-ray,AOI Test,Functional test
Pcb assembly one-stop service electronic manufacxturer service
Component sourcing Yes
Certificate IATF16949, ISO13485, ISO9001
Delivery time: PCB 3-8days
PCBA 10-20days
Tolerance of pcb ±5%
Max size of finish board 700*460mm
MOQ NO MOQ (1pcs)
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB outline Square,circle,irregular(with jigs)
Sub-assembly Plastic,metal,screen


Multilayer Prototype PCB Assembly 0



Detailed for Pcb Assembly Technical requirement:


1) Professional Surface-mounting and Through-hole soldering Technolog


2) Various sizes like 1206,0805,0603 components SMT technology


3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.


4) PCB Assembly With UL,CE,FCC,Rohs Approval


5) Nitrogen gas reflow soldering technology for SMT.


6) High Standard SMT&Solder Assembly Line


7) High density interconnected board placement technology capacity


Multilayer Prototype PCB Assembly 1


FASTPCBA is the experienced pcba manufacturer with procurement team average pcba industry experience over 15 years, providing the most competitive pcba cost and high quality pcb components for customers of medical pcba, automotive pcba,industrial control pcba etc.


With and IATF16949 and ISO13485, 9001,14000certificates,ERP pcb process control online, experienced engineer team,9 steps pcb testing, complete ESD protection & dust free smt workshop, dust free smt workshop & complete ESD protection, ERP pcb process control online, ensuring high quality pcb & pcba service.


Due to quality oriented, FASTPCBA has continuous orders in such fierce competition pcba market environment, welcome to consult or send a inquiry to get competitive pcb quotation.
