| Place of Origin: | China |
| Brand Name: | FASTPCBA |
| Certification: | IATF16949, ISO13485, ISO9001 |
| Model Number: | One-Stop PCBA Manufacturers |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 1 |
| Packaging Details: | PCB: Vacuum Packing/ PCBA: ESD Packing |
| Delivery Time: | 5 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 150000 Pieces per Month |
| Number Of Layers: | 1-48 | Material: | FR4, High TG FR4, High Frequency, Alum, FPC |
|---|---|---|---|
| Min Space: | 0.075mm | Sub-assembly: | Plastic,metal,screen |
| PCB Outline: | Square,circle,irregular(with Jigs) | Max Size Of Finish Board: | 700*460mm |
| High Light: | One Stop PCBA Electronics,Turnkey PCBA Electronics |
||
WHY CHOOSE JINGBANG?
1. 4 hours for pcba prototype, no MOQ (MOQ can be 1pcs,30 models PCB prototype per day, 3 million points per day.
2. Mature ISO9001 quality management system,IATF16949:2016 international automotive quality system standard and ISO13485:2016 medical device quality management system.
3. High-precision production machine, 5000 square meters dust-free anti-static workshop, strict workshop temperature and humidity monitoring.
4. 20 years of pcb & pcba manufacturing production and export experience, Famous brand manufacturers in China.
5. ERP order management system, one-click extraction of historical data , component inventory management is more convenient.
6. Free 24 hour online service among worldwide, problems feedback are no longer delayed.
7. Professional engineering team with an average of 15 years of industry experience.
8. NDA. We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level.
FASTPCBA is a turnkey pcb manufacturing and assembly factory indeed, with our own pcb factory separated from pcba company. PCBA service cover medical, automotive, industry, smart home, aviation, military, communication etc.
Process capability:
| Article | Description | Capability | |
| Sercive | PCB and SMT assembly with one-stop service | ||
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board cutting | Number of layers | 1-48 | |
|
Min.thickness for inner layers (Cu thickness are excluded) |
0.003”(0.07mm) | ||
| Board thickness | Standard | (0.1-4mm±10%) | |
| Min. | Single/Double:0.008±0.004” | ||
| 4layer:0.01±0.008” | |||
| 8layer:0.01±0.008” | |||
| Bow and twist | no more than 7/1000 | ||
| Copper weight | Outer Cu weight | 0.5-4 0z | |
| Inner Cu weight | 0.5-3 0z | ||
| Drilling | Min size | 0.0078”(0.2mm) | |
| Drill deviation | ±0.002″(0.05mm) | ||
| PTH hole tolerance | ±0.002″(0.005mm) | ||
| NPTH hole tolerance | ±0.002″(0.005mm) | ||
|
Solder mask
|
Color | Green,white,black,red,blue… | |
| Min solder mask clearanace | 0.003″(0.07mm) | ||
| Thickness | (0.012*0.017mm) | ||
| Silkscreen | Color | white,black,yellow,blue… | |
| Min size | 0.006″(0.15mm) | ||
| E-test | Function Test | 100% Functional test | |
| PCBA Testing | X-ray,AOI Test,Functional test | ||
| Pcb assembly | one-stop service electronic manufacxturer service | ||
| Component sourcing | Yes | ||
| Certificate | IATF16949, ISO13485, ISO9001 | ||
| Delivery time: | PCB | 3-8days | |
| PCBA | 10-20days | ||
| Tolerance of pcb | ±5% | ||
| Max size of finish board | 700*460mm | ||
| MOQ | NO MOQ (1pcs) | ||
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | ||
| PCB outline | Square,circle,irregular(with jigs) | ||
| package | QFN,BGA,SSOP,PLCC,LGA | ||
| Sub-assembly | Plastic,metal,screen | ||
