Detailed Product Description
Number Of Layers: 1-48 Min Space: 0.075mm
Max Size Of Finish Board: 700*460mm Component Sourcing: Yes
Min Line/space: 0.075mm PCBA Testing: X-ray,AOI Test,Functional Test
High Light:

One Stop Turnkey PCB Assembly


Multilayer Turnkey PCB Assembly

Turnkey Multilayer FR4 94V0 OEM PCB Assembly

PCB or PCB Assembly files requests

1. Gerber files of the bare PCB board
2. BOM (Bill of material) for assembly


To short the lead time, please kindly advise us if there is any acceptable components substitution.
3. Testing Guide & Test Fixtures if necessary
4. Programming files & Programming tool if necessary
5. Schematic if necessary


Multilayer Turnkey PCB Assembly 0


Process capability:


Article Description Capability
Sercive PCB and SMT assembly with one-stop service
Material Laminate materials FR4, high TG FR4, high frequency, alum, FPC
Board cutting Number of layers 1-48

Min.thickness for inner layers

(Cu thickness are excluded)

Board thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
Bow and twist no more than 7/1000
Copper weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)

Solder mask


Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
E-test Function Test 100% Functional test
PCBA Testing X-ray,AOI Test,Functional test
Pcb assembly one-stop service electronic manufacxturer service
Component sourcing Yes
Certificate IATF16949, ISO13485, ISO9001
Delivery time: PCB 3-8days
PCBA 10-20days
Tolerance of pcb ±5%
Max size of finish board 700*460mm
MOQ NO MOQ (1pcs)
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB outline Square,circle,irregular(with jigs)
Sub-assembly Plastic,metal,screen


Multilayer Turnkey PCB Assembly 1

FASTPCBA is the leading pcb manufacturing and pcb assembly factory globally, with ISO14000, 13485, ISO9001 and IATF16949 certificates simultaneously, can provide better pcba service for customers from Iot pcba, aerospace pcba, military pcba, communication pcba, industrial pcba, medical pcba, automotive pcba etc.


Multilayer Turnkey PCB Assembly 2


FASTPCBA keeps pace with the times, has imported advanced X-RAY, 3D AOI, selective wave soldering, MADATA, YAMAHA etc equiments, we can provide accurate pcb printing, precise pcb assembly, custom pcb manufacturing, original package componets agent service, save your cost and time at the same time.


Multilayer Turnkey PCB Assembly 3


FASTPCBA survival over 20 years, as our goal is always provide best quality pcba solution for customers from domestic and abroad like Brazil, Japan, America, Russia, Gemany, France, UK etc. FASTPCBA can turn your pcb design to pcba or pcb assp, welcome to inquiry and visit us in shenzhen china.
