| Place of Origin: | China |
| Brand Name: | FASTPCBA |
| Certification: | ISO13485, IATF16949, ISO9001 |
| Model Number: | Pcb Assembly Contract Manufacturer |
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | USD 0.1-3/ pcs |
| Packaging Details: | 1.Inner: PCB: Vacuum Packing PCBA: ESD Packing 2.Outer: Standard export carton 3.Customized package. |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000pcs/month |
| Service: | One-stop PCB And SMT Assembly | Layer Count: | 1-48 |
|---|---|---|---|
| MOQ: | No MOQ | PCBA Test: | X-ray,AOI Test,Functional Test |
| Solder Mask Color: | Yellow,green,blue,white,black | Max Size Of Finish Board: | 700*460mm |
| High Light: | FR4 PCB Assembly Service,0.003" PCB Assembly Service,4 Layer FR4 PCB Assembly |
||
ASTPCBA focus on muti-varieties and small batch quick turn pcb prototype over 20 years, with no MOQ, no need to open stencil, fastest pcb delivery in 4hs.
FASTPCBA insist on taking high quality pcb assembly route, we can flexiblely service for small batch pcb prototype, middle batch pcb manufacturing, mass pcb assembly for customers of automotive, medical, industrial control, military, smart home, power communication and aerospace with ISO9001, ISO13485, ISO14000 and IATF16949 certificates.
With ERP online control, complete quality management, advanced pcb printing & assembly devices, professional engineer team, we are confident to provide best quality and precise pcb assembly solutions.
| Article | Description | Capability |
| Material | Laminate materials | FR4, High TG FR4, High Frequency, Alum, FPC... |
| Board Cutting | Number of layers | 1-48 |
| Min.thickness for inner layers (Cu thickness are excluded) |
0.003”(0.07mm) | |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” | |
| 4 layer:0.01±0.008” | ||
| 8layer:0.01±0.008” | ||
| Bow and twist | no more than 7/1000 | |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z | |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) | |
| PTH hole tolerance | ±0.002″(0.005mm) | |
| NPTH hole tolerance | ±0.002″(0.005mm) | |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) | |
| Thickness | (0.012*0.017mm) | |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) | |
| Max Size of Finish Board | 700*460mm | |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | |
| PCB Outline | Square,circle,irregular(with jigs) | |
| Package | QFN,BGA,SSOP,PLCC,LGA | |
Delivery Time for PCB
| Layer | Prototype |
Mass Productions (above 30 m2 ) |
|
| Quick Turn | Unual Time | ||
| 2 | 24 hours | 3-4 days | 8-10 days |
| 4 | 48 hours | 5-6 days | 10-12 days |
| 6 | 72 hours | 6-8 days | 12-14 days |
| 8 | 96 hours | 8-10 days | 14-16 days |
| 10 | 120 hours | 12-14 days | 16-18 days |
| ... | ... | ... | ... |
Delivery Time for PCBA
| Order Conditions | Standard Delivery Date | The fastest Delivery Date |
| Prototype (<20 pcs) | 2 days | 8 hours |
| Small Volum (20-100 pcs) | 3 days | 12 hours |
| Medium Volum(100-1000 pcs) | 6 days | 24 hours |
| Mass productions (>1000 pcs) | Depends on BOM | Depends on BOM |
Small batch turnkey pcb assembly factory, smart home/ automotive/ medical/industry/ military/ communication/ aerospace customers prefer to cooperate with FASTPCBA over decades.
