0.5-4 oz Cu Weight ROHS Compliant PCB Assembly Service with 14 SMT Lines

Product Description:

The Solder Mask on our PCB boards comes in a variety of colors including Green, Blue, White, Black, and many more. This allows you to choose the color that best fits your design and style. Our SMT Production Line is made up of 14 machines which allows us to quickly and efficiently assemble your PCB boards.

We take pride in our PCB Quality System which is compliant with the latest ROHS standards. This ensures that your boards are free from hazardous materials and are environmentally friendly.

In addition to our top-quality PCB boards, we also offer THT and DIP services to meet all of your assembly needs. Our team of experts can help you design and assemble your boards to your exact specifications.

Overall, our PCB Assembly Service is perfect for those looking for a reliable and efficient way to prototype their electronic designs. Our top-quality PCB Prototype Board, variety of Solder Mask colors, SMT Production Line, and PCB Quality System make us the perfect choice for all of your PCB assembly needs.



Features:

• Product Name: PCB Assembly Service
• Drill Deviation: ±0.002”(0.05mm)
• Pcb Type: Rigid PCB, Flexible PCB, Rigid-flex PCB
• Min Line Width: 3.0mil
• Smt Production Line: 14
• Laminate: Single-Sided Board/Double-Sided Board
• Supports THT, SMT, PCBA, and DIP



Technical Parameters:

Technical Parameters	Values
Laminate	Single-Sided Board/Double-Sided Board
Board Cutting	V-cut,Routing
Drilling Bit Size	0.15-6.5mm
Minimum Line Width	3 Mil
Drill Deviation	±0.002”(0.05mm)
Product	PCB Prototype Board
PCB Quality System	ROHS
Lead Time	1-5 Days For PCB Assembly, 10-15 Days For Turnkey PCB Assembly
PCB Outline	Square, Circle, Irregular(with Jigs)
Copper	3oz



Applications:

Through-hole technology (THT) is a popular assembly method for electronic components that require a strong mechanical bond. THT components have leads that are inserted into holes on the PCB, and the leads are then soldered to the opposite side of the board. Our PCB assembly service can handle THT components with drilling bit sizes ranging from 0.15-6.5mm. Some of the product application scenarios for THT assembly include:

• Industrial control systems
• Power supplies
• Audio equipment

Surface mount technology (SMT) is a popular assembly method for electronic components that are small and lightweight. SMT components have no leads and are mounted directly onto the surface of the PCB. Our PCB assembly service can handle SMT components with a minimum size of 3.0mil. Some of the product application scenarios for SMT assembly include:

• Consumer electronics
• Medical devices
• Automotive electronics

Rigid-flex PCBs combine the benefits of both rigid and flexible PCBs. They are designed to be used in applications where high flexibility is required along with high rigidity. Our PCB assembly service can handle rigid-flex PCBs with precision and accuracy. Some of the product application scenarios for rigid-flex PCB assembly include:

• Aerospace and defense electronics
• Wearable devices
• Smartphones and mobile devices

Our PCB assembly service is a reliable and cost-effective solution for a wide range of electronics manufacturing needs. With our high-precision equipment and experienced technicians, we can handle THT, SMT and rigid-flex PCB assembly with ease. Contact us today to learn more about our services and how we can help you with your next electronics project.



FAQ:

A: PCB Assembly Service is a service offered by our company that assembles printed circuit boards (PCBs) with surface-mount technology (SMT) components. Our service includes the procurement of components, PCB fabrication, and assembly.

Q: What types of PCBs can be assembled?

A: We can assemble single-sided, double-sided, and multi-layer PCBs with up to 12 layers.

Q: Can I provide my own components for assembly?

A: Yes, you can provide your own components for assembly. However, we recommend using our component procurement service to ensure the highest quality and reliability of the components.

Q: What is the turnaround time for PCB assembly?

A: The turnaround time for PCB assembly depends on the complexity of the assembly and the quantity of PCBs. Typically, it takes 5-10 days for assembly after all components and PCBs are received.

Q: What is the minimum order quantity for PCB assembly?

A: The minimum order quantity for PCB assembly is 5 units. However, we recommend ordering a prototype batch of 10 units to test the design before placing a larger order.
