| Place of Origin: | China |
| Brand Name: | FASTPCBA |
| Certification: | IATF16949, ISO13485, ISO9001 |
| Model Number: | PCBA Manufacturers |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 0.5-30USD |
| Packaging Details: | PCB: Vacuum Packing/ PCBA: ESD Packing |
| Delivery Time: | 1-10 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 150000 Pieces per Month |
| Name: | PCBA Manufacturers | Laminate Materials: | FR4, High TG FR4, High Frequency, Alum, FPC |
|---|---|---|---|
| Number Of Layers: | 1-48 | Board Thickness: | Single/Double:0.008±0.004” |
| PCB Outline: | Square,circle,irregular(with Jigs) | Sub-assembly: | Plastic,metal,screen |
FASTPCBA is the independent export pcba factory over 20 years, who are recognized as the top 10 pcba manufactuerer global, serving for customers of aviation pcba, automotive circuit board, medical pcba, industrial pcba, communication pcba, smart home pcba, safety protection pcba and military pcba etc.
We produces pcba for our customers from various industries, from military and aerospace pcba to medical, automotive, industry, communication, smart home, communication .
PCBA Manufacturing Capability
| 1 | Description | PCB Specification |
| 2 | Material | FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum |
| 3 | Layer | 1-48 |
| 4 | Board Thickness | 0.2mm- 4.0mm |
| 5 | Board Thickness Tolerance | +/-10% |
| 6 | Copper thickness | 17.5um-175um (0.5oz-5oz) |
| 7 | Min Trace Width | 0.15mm |
| 8 | Min Space Width | 0.15mm |
| 9 | Min Drilling Dia | 0.2mm |
| 10 | PTH copper thickness | 0.4-2mil(10-50um) |
| 11 | Tolerance of Etching | ±1mil(±25um) |
| 12 | V-cut angle | 25°,30°,45°,60° |
| 13 | Pearl Strength of line | ≥ 6lb/in(≥ 107g/mm) |
| 14 | Impedance control and tolerance | 50Ω±10% |
| 15 | Twist&Wrap | ≤ 0.5% |
| 16 | Soldermask | Green, Red, Blue, White, Black, Yellow |
| 17 | Surface Finish/Plating | HASL/Lead Free HASL/OSP/Gold Plating/Immersion Gold/ENIG |
| 18 | Certificate | IATF16949, ISO13485, ISO9001 |
| 19 | File | Protel 99se/P-CAD/Autocad/Cam350 |
| 20 | Inner packing | Vacuum packing,Plastic bag |
| 21 | Outer packing | Standard carton packing |
We can offer one stop service from PCB designing, manufacturing to components assembling, testing and housing.
