| Place of Origin: | China |
| Brand Name: | FASTPCBA |
| Certification: | IATF16949, ISO13485, ISO9001 |
| Model Number: | PCB Assembly |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 1-20 |
| Packaging Details: | PCB: Vacuum Packing/ PCBA: ESD Packing |
| Delivery Time: | 5 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 150000 Pieces per Month |
| Laminate Materials: | FR4, High TG FR4, High Frequency, Alum, FPC | Number Of Layers: | 1-48 |
|---|---|---|---|
| Board Thickness: | 0.1-4mm±10% | Cu Weight: | 0.5-4 0z |
| Min Line/space: | 0.075/0.075mm | Color: | Green,white,black,red,blue… |
| High Light: | SMT PCB Assembly Service,16 Layer PCB design manufacturing |
||
PCBA Technical Capabilities:
| Layer | Prototype |
Mass Productions (above 30 m2 ) |
|
| Quick Turn | Unual Time | ||
| 2 | 24 hours | 3-4 days | 8-10 days |
| 4 | 48 hours | 5-6 days | 10-12 days |
| 6 | 72 hours | 6-8 days | 12-14 days |
| 8 | 96 hours | 8-10 days | 14-16 days |
| 10 | 120 hours | 12-14 days | 16-18 days |
| ... | ... | ... | ... |
Delivery Time for PCBA
| Order Conditions | Standard Delivery Date | The fastest Delivery Date |
| Prototype (<20 pcs) | 2 days | 8 hours |
| Small Volum (20-100 pcs) | 3 days | 12 hours |
| Medium Volum(100-1000 pcs) | 6 days | 24 hours |
| Mass productions (>1000 pcs) | Depends on BOM | Depends on BOM |
PCB board manufacture and PCBA service:
* PCB board made, circuit board parts purchased by us
* Electronic testing circuit board or PCBA
* Fast delivery, anti-static package
* RoHS Directive-compliant, lead-free
* One stop service from PCB design, PCB layout, PCB manufacture, components
purchasing, PCB assembly, test, packing and PCB delivery
* Electronic manufacturing service
Detailed terms for PCB assembly:
* Technical requirement:
1. Professional surface-mounting and through-hole soldering technology
2. Various sizes like 1206, 0805, 0603 components SMT technology
3. ICT (in circuit test), FCT (functional circuit test) technology
4. PCB assembly with UL, CE, FCC, RoHS approval
5. Nitrogen gas reflow soldering technology for SMT
6. High standard SMT and solder assembly line
7. High density interconnected board placement technology capacity
