Product Details:
|
| Turnkey PCBA: | PCB+components Sourcing+assembly+package | Lead Time: | Prototype: 15 Work Days. Mass Order: 20~25 Work Days |
|---|---|---|---|
| Testing On Products: | Flying Probe Test, X-ray Inspection, AOI Test, Functional Test | Quantity: | Min Quantity: 1000pcs. Prototype, Small Order, Mass Order, All OK |
| Files We Need: | Assembly: Pick-N-Place File | PCB Panel Size: | Min Size: 0.25*0.25 Inches(6*6mm)，Max Size: 20*20 Inches(500*500mm) |
| Copper Thickness: | 1oz,0.5-2.0 Oz,1-3oz,0.5-5oz,0.5-4oz | Base Material: | FR4, Aluminium, TG, Rogers, CEM-1 |
| High Light: | 2 layer pcb assembly,high volume pcb manufacturing,high volume pcb production |
||
Advantages of multilayer circuit boards
1, the multi-layer circuit board assembly density is high, the size is small, with the volume of electronic products is getting smaller and smaller, the function of PCB circuit board is also put forward higher requirements, the demand for multi-layer circuit board is also increasing.
3. For the high-frequency circuit, after entering the ground, the signal line has a stable and low characteristic impedance to the ground, and the characteristic impedance of the power circuit is greatly reduced, which has a significant intercepting effect.
4. For electronic products with higher requirements for heat dissipation function, metal core heat dissipation layer can be set up on multi-layer circuit board, which is convenient to satisfy the requirements of shielding, heat dissipation and other special functions.
DIP
1,The process of DIP processing is: putting in the hole →AOI→ wave soldering → cutting pin →AOI→ correction → washing → quality inspection.
2,After wave soldering, The products will be will scanned by AOI equipment to ensure that no error occurs.
| No. | Types Of Assembly | File Format | Component Footprinr | Component Package | Testing Produres | Produres | Others |
| 1 | SMT ASSEMBLY | Gerber RS-274X | 0201,0402,0603... | Reels Package | Visual Inspection | Lead-Free(Rohs) | Custom Reflow Profile |
| 2 | SMT & THT Assembly | BOM(.xls,.csv,.xlsx) | BGA,QFN,QFP,PLCC | Cut Tape Package | X-Ray Inspection | Leaded Solder | Standard Reflow Profile |
| 3 | 2 sided SMT,THT Assembly | Pick-N-Place/XY file | SOIC,POP...Connectors | Tube and Tray | AOI,ICT(In-Circuit Test) | Reflow Soldering | Smallest Size:0.2"x0.2" |
| 4 | Mixed Assembly | ... | Small Pitch of 8 Mils | Loose parts and bulk | Functional Testing | Wave Soldering | Largest Size:15"x"20 |
| Turnkey PCBA | PCB+components sourcing+assembly+package | ||||
| Assembly details | SMT and Thru-hole, ISO lines | ||||
| Lead Time | Prototype: 15 work days. Mass order: 20~25 work days | ||||
| Testing on products | Flying Probe Test, X-ray Inspection, AOI Test, functional test | ||||
| Quantity | Min quantity: 1pcs. Prototype, small order, mass order, all OK | ||||
| Files we need | PCB: Gerber files(CAM, PCB, PCBDOC) | ||||
| Files we need | Components: Bill of Materials(BOM list) | ||||
| Files we need | Assembly: Pick-N-Place file | ||||
| PCB panel Size | Min size: 0.25*0.25 inches(6*6mm) | ||||
| Max size: 20*20 inches(500*500mm) | |||||
| PCB Solder Type | Water Soluble Solder Paste, RoHS lead free | ||||
| Components details | Passive Down to 0201 size | ||||
| Components details | BGA and VFBGA | ||||
| Components details | Leadless Chip Carriers/CSP | ||||
| Components details | Double-sided SMT Assembly | ||||
| Components details | Fine Pitch to 0.8mils | ||||
| Components details | BGA Repair and Reball | ||||
| Components details | Part Removal and Replacement | ||||
| Component package | Cut Tape,Tube,Reels,Loose Parts | ||||
| PCB assembly | Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing | ||||
1. Program and functional test and package by Free.
2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.
3. Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 21 years experience.
4. Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001, ISO14001,IATF16949
Q: What files do you use in PCBA fabrication?
A: Gerber or Eagle, BOM listing, PNP and Components Position.
Q: Is it possible you could offer sample?
A: Yes, we can custom samples for your testing before mass production.
Q: How much time could I get the quotation after sent Gerber, BOM and test procedure?
A: Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.
Q: How can I know the process of my PCBA production?
A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and Testing.
Q.What is the warranty?
The warranty is 2years.
