| Place of Origin: | China |
| Brand Name: | FASTPCBA |
| Certification: | IATF16949, ISO13485, ISO9001 |
| Model Number: | Industrial PCBA Assembly |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | 1 |
| Packaging Details: | PCB: Vacuum Packing/ PCBA: ESD Packing |
| Delivery Time: | 5 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 150000 Pieces per Month |
| Number Of Layers: | 1-48 | Material: | FR4, High TG FR4, High Frequency, Alum, FPC |
|---|---|---|---|
| Min Space: | 0.075mm | Min Line: | 0.075mm |
| Function Test: | 100% Functional Test | PCBA Testing: | X-ray,AOI Test,Functional Test |
| High Light: | Turnkey PCB Manufacturing Assembly,ISO Industrial PCBA |
||
PCB Capability
| Items | PCBA capacity |
| Product name | PCB and SMT assembly with one-stop service |
| Assembly details | SMT and Thru-hole, ISO SMT and DIP lines |
| Testing on products | Testing jig/mold , X-ray Inspection, AOI Test, Functional test |
| Quantity | Min quantity : 1pcs. Prototype, small order, mass order, all OK |
| Files needed | PCB : Gerber files(CAM, PCB, PCBDOC) |
| Components : Bill of Materials(BOM list) | |
| Assembly : Pick-N-Place file | |
| PCB Panel Size | Min size : 0.25*0.25 inches(6*6mm) |
| Max size : 1200*600mm | |
| Components details | Passive Down to 0201 size |
| BGA and VFBGA | |
| Leadless Chip Carriers/CSP | |
| Double-sided SMT Assembly | |
| Fine BGA Pitch to 0.2mm(8mil) | |
| BGA Repair and Reball | |
| Part Removal and Replacement | |
| Component package | Cut Tape, Tube, Reels, Loose Parts |
| PCB+ assembly process | Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity |
FASTPCBA is the best choice for high quality pursuit customers of communication pcba, automotive pcba, medical pcba, industry pcba, military pcba, aerospace pcba etc.
FASTPCBA is the professional pcb factory over 20 years, who has been audited by gemany bosch. With ISO & IATF certificate, 5000㎡+ dust free and ESD protection smt workshop, FASTPCBA gets the favor of customers among aerospace, military, power communication, smart home, industrial control, automotive, medical.
FASTPCBA is famous for precise and accutate pcb manufacturing and assembly capacibility among pcba industry with 70000 points/ h placement speed, can mount 0201 & 01005 devices, identify 0.25 pitch BGA and 0.2MM connectors, we can better satisfy high density, fine pith pcb assembly requirements.
FASTPCBA is the best one-stop pcba assembly supplier in china, it’s our continuous pursuit to better serve and creat more values for customers domestic and abroad.
